Power Integrations, the leader in gate driver technology for medium- and high-voltage inverter applications, today announced the SCALE EV family of gate-driver boards for Infineon EconoDUAL modules. Suitable for original, clone and new SiC variants, the driver targets high-power automotive and traction inverters for EV, hybrid and fuel-cell vehicles including buses and trucks as well as construction, mining and agricultural equipment.
SCALE EV board-level gate drivers incorporate two reinforced gate-drive channels, associated power supplies and monitoring telemetry. The new boards are automotive-qualified and ASIL B certified, enabling the implementation of ASIL C traction inverter designs. The first SCALE EV family member to be released is the 2SP0215F2Q0C, designed for the EconoDUAL 900 A 1200-volt IGBT half-bridge module.
Peter Vaughan, director of automotive business development at Power Integrations, said: “Gate-driver design is critical to both the performance and reliability of electric vehicles. By offering a product where the development, testing and qualification plus ASIL certification have already been done, we are dramatically reducing development time and cost.”
The high level of integration provided by innovative new driver ICs enables the entire driver board, including gate power, to fit onto the outline of the power module, while still providing the spacing necessary for reinforced isolation according to the IEC 60664 standard. The ASIC package provides 11.4 mm of creepage and clearance, specifically designed to meet the requirements for 800‑volt vehicle system voltages. Input and output lines to the system microcontroller are connected via two independent onboard connectors to meet functional safety requirements. A single 5 V supply per channel is required, with other isolated voltages being generated on the board itself.
The SCALE EV gate-driver family is rated at 1200 V for 400-volt and 800-volt systems and supports both silicon carbide (SiC) MOSFETs and silicon IGBTs. The design carries a 5500-meter altitude rating and is optionally available with conformal coating for technical cleanliness requirements. The design includes a wide range of protection provisions, including active, short-circuit, active discharge of connected DC-link capacitor, overvoltage limitation via active gate control, a diagnostic functions such as gate monitoring, signal transmission monitoring and on-chip temperature monitoring, and short-circuit and the over-current response of less than one microsecond for SiC MOSFETs and less than three microseconds for IGBTs.
