    Photonic memory devices of Next generation are light-written, ultrafast and energy efficient

    A hybrid technology, showing the advantages of both, light and the magnetic hard drives, has been developed by researchers of the Institute of Photonic Integration of the Eindhoven University of Technology (TU/e). Ultra-shot (femtosecond) light pulses allows data to be directly written in a magnetic memory in a fast and highly energy-efficient manner.

    Moreover, as soon as the information is written (and stored), it moves forward leaving space to empty memory domains to be filled in with new data. The research promises to revolutionize the process of data storage in future photonic integrated circuits.

    Data are stored in hard drives in the form of ‘bits’, tiny magnetic domains with a North and a South pole. The direction of these poles (‘magnetization’), determines whether the bits contain a digital 0 or a 1. Writing the data is achieved by ‘switching’ the direction of the magnetization of the associated bits.

    Synthetic ferrimagnets

    Conventionally, the switching occurs when an external magnetic field is applied, which would force the direction of the poles either up (1) or down (0). Alternatively, switching can be achieved via the application of a short (femtosecond) laser pulse, which is called all-optical switching, and results in a more efficient and much faster storage of data.

    Mark Lalieu, PhD candidate at the Applied Physics Department of TU/e: ‘All-optical switching for data storage has been known for about a decade. When all-optical switching was first observed in ferromagnetic materials, amongst the most promising materials for magnetic memory devices, this research field gained a great boost’. However, the switching of the magnetization in these materials requires multiple laser pulses and, thus, long data writing times.

    Storing data a thousand times faster

    Lalieu, under the guidance of Reinoud Lavrijsen and Bert Koopmans, was able to achieve all-optical switching in synthetic ferrimagnets, a material system highly suitable for spintronic data applications, using single femtosecond laser pulses, thus exploiting the high velocity of data writing and reduced energy consumption.

    ‘On-the-fly’ data writing

    In addition, Lalieu integrated all-optical switching with the so-called racetrack memory, a magnetic wire through which the data, in the form of magnetic bits, is efficiently transported using an electrical current. In this system, magnetic bits are continuously written using light, and immediately transported along the wire by the electrical current, leaving space to empty magnetic bits and, thus, new data to be stored.

    Koopmans: “This ‘on the fly’ copying of information between light and magnetic racetracks, without any intermediate electronic steps, is like jumping out of a moving high-speed train to another one. From a ‘photonic Thalys’ to a ‘magnetic ICE’, without any intermediate stops. You will understand the enormous increase in speed and reduction in energy consumption that can be achieved in this way.”
