All new Energy Metering ICs introduced for Next-Generation Smart Meter Systems

94

Mouser Electronics, Inc., the industry’s leading New Product Introduction (NPI) distributor with the widest selection of semiconductors and electronic components, is now stocking ADE9xxx energy metering integrated circuits (ICs) from Analog Devices. Ideal for meeting the needs of next-generation smart metering applications, the ADE9xxx energy metering ICs deliver highly accurate measurements of apparent energy (kVA), active energy (kWh), reactive energy (kVAR), rms, and power quality, ideal for meeting the needs of next-generation smart metering, industrial instruments, single-phase and polyphase revenue meters, and energy-monitoring applications.

The Analog Devices ADE9xxx energy metering IC portfolio available from Mouser Electronics comprises the accurate and efficient ADE9000, ADE9078, and ADE9153A devices and associated evaluation tools. The ADE9000 and ADE9078 analog front ends (AFEs) offer complete power monitoring capabilities over a broad dynamic range, integrating seven high-performance analog-to-digital converters (ADCs), a high-end reference, and a flexible digital signal processing core (DSP) into a single device. The ADE9153A ICs integrate three ADCs and mSure technology, using a meter to automatically calibrate current and voltage channels without a reference meter.

Analog Devices’ ADE9xxx energy metering ICs are supported by several evaluation tools that enable developers to test and evaluate functions and performance of the devices. The ADI EVAL-ADE9000EBZ evaluation board works in conjunction with the controller board for the EVAL-SDP-CB1Z system demonstration platform and the ADE9000 evaluation software, while the ADI EVAL-ADE9078EBZ evaluation board can operate in a standalone mode or in conjunction with the EVAL-SDP-CB1Z platform to approximate a three-phase meter implementation.

Mouser also offers the EV-ADE9000SHIELDZ and EV-ADE9153ASHIELDZ Arduino-compatible shields, which enable prototyping and evaluation of power and energy measurement systems with the ADE9000 and ADE9153A AFEs, respectively.
