Unveiling new silent switcher series delivers low EMI operation and output current configurations

Analog Devices, Inc. (ADI)  introduced the LT8650S, LT8652S and LT8653S dual-channel 4A/8.5A/2A synchronous step-down Silent switcher converters targeted for automotive, communications and solid state drive power supplies. The proprietary Silent Switcher 2 architecture along with spread spectrum frequency modulation ensures PCB layout robustness to achieve ultra-low EMI performance that easily meets CISPR25 emissions.

The LT8650S, LT8652S and LT8653S are also differentiated with their stackable-friendly outputs for higher current applications.  Outputs can be paralleled to scale up or down the output current based on the system need while optimizing thermal performance. This also helps to minimize inventory and qualification time with a single device. For example, the LT8652S provides 8.5A DC from each channel simultaneously or up to 12A on either channel. Synchronizing two LT8652S chips can achieve a 4-phase, 34A supply.

LT8650S/LT8652S/LT8653S Key Features:

  • Silent Switcher 2 Technology with Integrated Bypass Capacitors meets CISPR25 Emissions
  • Ultralow Quiescent Current Burst Mode® for Light Load operation
  • Up to 12A (LT8652S) on one channel
  • Adjustable and Synchronizable Frequency (300kHz to 3MHz)

Pricing and Availability



Product Full

Production



Price Each Per 1,000 Packaging
LT8650S NOW $5.75 4mm x 6mm LQFN
LT8652S NOW $4.50 4mm x 7mm LQFN
LT8653S NOW $4.02 4mm x 3mm LQFN



For more information, visit www.analog.com
