SiTime’s Automotive MEMS Oscillators Deliver 30 Times Better Robustness
- AEC-Q100 compliant, engineered for ASIL
- Best stability over -55 to +125°C for in-vehicle communications
- Unique EMI reduction features for environmental compliance
SiTime Corporation, the leader in MEMS-based timing solutions and a wholly owned subsidiary of MegaChips Corporation (Tokyo Stock Exchange: 6875), on January 10, 2017, introduced two families of ultra-robust AEC-Q100-
“The automotive industry is going through a massive transformation, with new features such as advanced safety and driver assistance systems, electrification, automation and real-time big data analytics. The usage of electronic components in automobiles is increasing rapidly and requires stringent levels of quality, reliabilityand performance,” said Piyush Sevalia, executive vice president of marketing at SiTime. “MEMS technologies are playing a significant role in this transformation. SiTime is leveraging our revolutionary silicon MEMS, advanced analog technology and standard semiconductor packaging to provide unique timing solutions that deliver the highest reliability and dynamic performance under extreme temperatures, shock and vibration.”
SiTime’s new automotive product families offer a unique combination of the widest frequency range, tightest stability at ±20 ppm and the best reliability. The SiT2024/25 oscillators are optimized for under-the-hood systems such as engine control, transmission control, active suspension control, electronic steering and other ECUs. These oscillators are available in a SOT23-5 leaded package to enable visual inspection and the best solder joint reliability, especially in hot and cold environments. The SiT8924/25 oscillators, available in industry-standard QFN footprints as small as 2.0 x 1.6 mm, are ideal for camera modules and other small form factor systems.
About the SiT2024/2025 and SiT8924/8925 Oscillators
SiTime’s automotive oscillators are 30 times more robust than quartz oscillators and deliver the following features and benefits.
- AEC-Q100 qualified, Grade 1 (-40°C to +125°C), Grade 2 (-40°C to +105°C) and extended temperature range (-55°C to +125°C)
- SiT2024/2025: SOT23-5 leaded package for best board-level solder-joint reliability and ease-of-use in manufacturing and test
- SiT8924/8925: Five package options in industry-standard oscillator footprints
- Excellent frequency stability at ±20 ppm for best timing margin
- Highest reliability at over 1 billion hours MTBF (< 1 FIT)
- Best shock resistance at 50,000 g
- Best vibration resistance at 70 g
- Lowest vibration sensitivity (g-sensitivity) at 0.1 ppb/g
- Widest frequency range of 1 to 137 MHz with 6 decimal places of accuracy
- Unique, programmable output drive strength for EMI reduction
- Supply voltage options of 1.8V, 2.5 to 3.3V
The SiT2024, SiT2025, SiT8924 and SiT8925 oscillators are in production now. Pricing information and Production Part Approval Process (PPAP) documentation, compliant with the AIAG manual, is available upon request.
