Semiconductor combination yields more power from solar cells

The efficiency of commercially available solar modules can only be increased to a limited extent, according to German researchers at the Karlsruhe Institute of Technology, Germany.

As they start working on the new Capitano project, which commenced in July, 2019, the team led by Professor Michael Powalla with Ulrich Paetzold say, “Significantly more potential is offered by the use of two light-active layers in tandem solar modules. This promising technology could be the future of photovoltaics.”

Project partners are the Center for Solar Energy & Hydrogen Research Baden-Württemberg (ZSW) as coordinator, KIT and the company NICE Solar Energy in Schwäbisch Hall. They are combining thin-film solar modules based on perovskite semiconductors with semiconductors made of copper, indium, gallium and selenium (CIGS). The combination enables highly efficient tandem solar cells with an efficiency potential of over 30% with all the advantages of thin-film technology.

Higher efficiencies

Tandem solar modules consist of two different types of solar modules stacked on top of each other, which make better use of the spectrum of sunlight than the respective single solar cell. As a result, the multiple solar modules have a higher efficiency. Significantly more than 30% are theoretically possible – with simple silicon solar cells, for example, the theoretical conversion limit is only 29.3% due to physical material properties.

There are now several variants of tandem modules available. In CIGS perovskite development, a perovskite solar cell converts the light into electricity in the visible part of the solar spectrum. The underlying CIGS solar cell absorbs the light in the near-infrared spectrum, which penetrates the perovskite solar cell. Both solar cells use thin-film technologies that can be produced on square-meter substrates. This could significantly reduce costs while at the same time achieving high efficiency, says the KIT team.

Prof. Powalla, who is also a Member of the Executive Board and Head of Photovoltaics at ZSW, said of the consortium’s leading composition, “I expect great progress in the further development of this expertise, from the basics to the mass production of the project’s promising technology.”

Paetzold, junior research group leader at KIT, added, “We are developing the next generation of highly efficient thin-film tandem solar modules, which have an efficiency of more than 30%. Promising fields of application are, for example, highly efficient solar modules for building-integrated photovoltaic solutions.”
