OMRON’s Third Wave of Factory Automation Devices Built on Common Design Platform

New products and their features:

DIN Track Terminal Blocks: XW5T

The XW5T DIN Track Push-in Plus Terminal Blocks double its line-up from 18 to 36 models. For terminal blocks with a width of 5.2 mm (maximum rated current: 24 A) and 6.2 mm (maximum rated current: 32 A), internal wiring of 1:2 and 2:2 type for branching and 2 tier type for space-saving are added. The workability and reliability of the XW5T with OMRON’s unique Push-In Plus Terminal Blocks can be used for wider applications.

Specifications:

Connection method: Push-In Plus terminal blocks
Width: 3.5 mm, 5.2 mm, 6.2 mm
Maximum applicable wire size: 1.5 mm²(AWG14), 4.0 mm²(AWG12), 6.0 mm²(AWG10)

Push-In Plus Terminal Block Series: G70V (internal connection models)

The G70V I/O Relay Terminals from Push-In Plus Terminal Block series, released in April 2016, now have models with internal connections between I/O terminals and in which wiring can be crossed-over. The input models have 16 points/common and output models have 4 points/common X 4 to increase the freedom in cross-over wiring and greatly reduce wiring work.

Series:

G70V I/O Relay Terminals

Specification:

Connection method: Push-In Plus Terminal Blocks
I/O: inputs, outputs
Number of I/O points: 16 points
Internal connections between I/O terminals: input models: 16 points/common, output models: 4 points/common X 4
Common line on connector side: NPN, PNP

Liquid Leakage Sensor Amplifiers with sensor disconnection detection supporting plus common output (PNP) type: K7L-AT50DPB/-UDPB

For the slim shape and high-precision liquid leakage detection, the K7L series has been utilized in a wide range of fields including semiconductor production equipment and building automation. A self-diagnosis function to detect disconnection of sensing bands (sensor part) and plus common outputs will detect liquid leakage which can lead to facility failure and stoppage more safely for worry-free use.

Specifications:

Connection method: Push-In Plus terminal blocks
Output configuration: plus common, 30 VDC, 100 mA
Dimension (WHD) of main body and Push-In Socket: 15.5 mm/90 mm/83 mm
Safety standards: CE, UL(Recognition), UL(Listed), and S mark

Liquid Leakage Sensor Amplifiers with sensor disconnection detection supporting plus common output (PNP) type: K7L-AT50DPB/-UDPB

For the slim shape and high-precision liquid leakage detection, the K7L series has been utilized in a wide range of fields including semiconductor production equipment and building automation. A self-diagnosis function to detect disconnection of sensing bands (sensor part) and plus common outputs will detect liquid leakage which can lead to facility failure and stoppage more safely for worry-free use.

Specifications:

Connection method: Push-In Plus terminal blocks
Output configuration: plus common, 30 VDC, 100 mA
Dimension (WHD) of main body and Push-In Socket: 15.5 mm/90 mm/83 mm
Safety standards: CE, UL(Recognition), UL(Listed), and S mark

Switch Mode Power Supplies: S8VK-S (30 W)

New 30-W models join the S8VK-S series. The wider lineup of the S8VK-S series meets customer needs for a small-capacity system, and modification or addition of components to control panels. Environmental resistance, the strength of the S8VK-S, is the same (ambient operating temperature range of -40 to 70°C and others) for stable operation in various environments.

Specifications:

Connection method: Push-In Plus terminal blocks
Power rating: 30 W
Dimension (WHD): 32 mm/90 mm/90 mm
