With the booming growth of the Internet of Things (IoT) endpoints, security is sometimes an afterthought for many designers, increasing the risk of exposing intellectual property (IP) and sensitive information. To address the growing need for security, the new SAM L10 and SAM L11 MCU families are now available from Microchip Technology Inc.
The new MCU families are based on the Arm Cortex-M23 core, with the SAM L11 featuring Arm TrustZone for Armv8-M, a programmable environment that provides hardware isolation between certified libraries, IP and application code. Microchip enables robust security by including chip-level tamper resistance, secure boot and secure key storage that, when combined with TrustZone technology, protects customer applications from both remote and physical attacks.
Both MCU families offer the industry’s lowest power consumption, as well as have capacitive touch capability with best-in-class water tolerance and noise immunity. When benchmarked for power consumption the SAM L10 received a ULPMark score of 405, which is over 200 percent better performance than nearest competitor certified by EEMBC, the Embedded Microprocessor Benchmark Consortium. Microchip uses proprietary picoPower technology to provide industry-leading low power consumption in active and all sleep modes.
“IoT endpoints often require low power and high security,” said Rod Drake, vice president of Microchip’s MCU32 business unit. “However, the growth of IoT nodes is happening so fast that security is not always addressed. The features of the SAM L11 are exactly what customers need to plan for security early in the design cycle.”
In addition to TrustZone technology, the SAM L11 security features include an on-board cryptographic module supporting Advanced Encryption Standard (AES), Galois Counter Mode (GCM) and Secure Hash Algorithm (SHA). The secure boot and secure key storage with tamper detection capabilities establish a hardware root of trust. It also offers secure bootloader for secure firmware upgrades. Microchip has partnered with Trustonic, a member of Microchip’s Security Design Partner Program, to offer a comprehensive security solution framework that simplifies implementation of security and enables customers to introduce end products faster. Microchip has also partnered with Secure Thingz and Data I/O Corporation to offer secure provisioning services for SAM L11 customers that have a proven security framework.
Both MCU families offer Microchip’s latest generation Peripheral Touch Controller (PTC) for capacitive touch capabilities. Designers can easily add touch interfaces that provide an impressively smooth and efficient user experience in the presence of moisture and noise while maintaining low power consumption. The touch interface makes the devices ideal for a myriad of automotive, appliance, medical and consumer Human Machine Interface (HMI) applications.
Availability
SAM L10 and SAM L11 devices are available today in a variety of pin counts and package options in volume production quantities.
- Devices in the SAM L10 series are available in 10,000-unit quantities.
- Devices in the SAM L11 series are available in 10,000-unit quantities.
- The SAM L10 and SAM L11 Xplained Pro Evaluation Kits are available (DM320204 and DM320205 respectively).
For more information visit www.microchip.com/SAML11.
