Solving trade-off between Fast Response Time and Low EMI Maxim unveils Automotive LED Controller

MAX20078 provides high performance, ease of design, and fast time-to-market for advanced front lighting applications, For Exterior Lighting and Improved Safety Applications

Maxim

The MAX20078 synchronous buck, high-brightness LED controller from Maxim Integrated Products, Inc.  is the only product available which provides both fast response time and low electromagnetic interference (EMI) for exterior LED lighting and improved safety applications. Ideal for matrix lighting designs, the LED controller allows designers to achieve high performance, ease of design, and fast time-to-market.

In advanced lighting applications such as matrix lighting, LED drivers and controllers have challenges when switching LEDs at high speeds which can cause overshoots and undershoots in current. These applications are not easy to design, as they require numerous LEDs located in a densely-concentrated area and EMI can be especially difficult to eliminate. Automakers spend time, money, and effort trying to achieve low EMI as they experiment with different layouts and filtering methods.

The MAX20078 provides ultra-fast response times enabling smoother transient responses. While eliminating the need for external compensation components, it also offers a wide dimming ratio and features both integrated fault protection and monitoring circuitry. The MAX20078 allows for fast LED switching and low EMI so that designers no longer need to sacrifice one for the other. These benefits, along with simplified design and flexible switching frequencies, allow designers to achieve faster time-to-market.

MAX20078-Block-Diagram

Key Advantages

  • High Performance: Ultra-fast response times enable advanced lighting designs
  • Ease of design: Low EMI; no compensation components required; can be programmed using switching frequencies from 100kHz up to 1MHz
  • Fast time-to-market: Integration of components and programmable switching frequency for a simple, flexible design

Availability and Pricing

  • Pricing for MAX20078 and MAX20078EVKIT evaluation kit available upon request

For more visit : https://www.maximintegrated.com.
