    Toshiba Adds SOIC Packages to Lineup of CMOS Logic ICs

    Toshiba America Electronic Components, Inc. (TAEC) on Dec 07, 2016, announced the availability of a line of CMOS logic ICs in a small outline integrated circuit (SOIC) packages: the 74HCxxxD series. These products support flow and reflow soldering, and are suitable for industrial equipment and digital home appliances with logic levels of 6V and lower. The 63 new part numbers in the 74HCxxxD series consist of the most commonly used 74-series logic functions, bringing the total number of CMOS logic ICs offered by Toshiba to more than 300.

    An SOIC is a surface-mounted integrated circuit that occupies an area that is approximately 30–50 percent less than an equivalent dual in-line package (DIP) with a thickness that is 70 percent smaller. This smaller size is well suited to applications that require a smaller PCB footprint. Toshiba’s ICs are available in industry standard packages of SOIC14, SOIC16, and SOIC20, and include a range of functionalities such as various gate types, flip flops, buffers, multiplexers, serial/parallel shift registers and more.

    Product Lineup

    Part Number

    Logic Function

    74HC00D

    Quad 2-input NAND gate

    74HC02D

    Quad 2-input NOR gate

    74HC03D

    Quad 2-input NAND gate with open-drain

    74HC08D

    Quad 2-input AND gate

    74HC21D

    Dual 4-input NAND gate

    74HC32D

    Quad 2-input OR gate

    74HC86D

    Quad 2-input XOR gate

    74HC04D

    Hex inverter

    74HC05D

    Hex inverter with open-drain

    74HC14D

    Hex schmitt inverter

    74HC123D

    Dual monostable multivibrator

    74HC125D

    Quad 3-state buffer

    74HC132D

    Quad 2-input Schmitt NAND

    74HC138D

    3-to-8 line Demultiplexor

    74HC139D

    Dual 2-to-4 Demultiplexor

    74HC151D

    8-to-1 Multiplexor

    74HC153D

    Dual 4-to-1 Multiplexor

    74HC157D

    Quad 2-to-1 Multiplexor

    74HC164D

    Parallel-out 8-bit Shift Register

    74HC166D

    Parallel-in 8-bit Shift Register

    74HC74D

    Dual D Flip-Flop

    74HC174D

    Hex D Flip-Flop

    74HC175D

    Quad D Flip-Flop

    74HC244D

    Octal buffer with 3-state outputs

    74HC245D

    Octal bus transceiver with 3-state outputs

    74HC259D

    8-bit addressable latch

    74HC273D

    8-bit register with asynchronous clear

    74HC373D

    Octal transparent latch with 3-state outputs

    74HC374D

    Octal register with 3-state outputs

    74HC393D

    Dual 4-bit binary counter

    74HC540D

    Inverting octal buffer with 3-state outputs

    74HC541D

    Non-inverting octal buffer with 3-state outputs

    74HC573D

    Octal D-type transparent latch with 3-state outputs

    74HC4049D

    Hex inverting Buffer

    74HC4050D

    Hex non-inverting Buffer

    74HC4051D

    8-channel analog Mux/Demultiplexer

    74HC4052D

    Dual 4-channel analog Mux/Demultiplexers

    74HC4053D

    Triple 2-channel analog Mux/Demultiplexers

    74HC4066D

    Quad Bilateral Switches

    Pricing and Availability

    Toshiba’s new CMOS logic ICs in SOIC packages are available now. For more details, samples and pricing information, please contact your local Toshiba Sales Office.
